About The Meter
2
SECTION 2. ABOUT THE METER
2.1 DESCRIPTION
The Digital Programmable Strain meter is a value packed indicator/controller. Four full
digits and broad scaling capability allow for display in virtually all engineering units.
A wide variety of DC current and voltage input ranges cover typical strain applications.
Standard features include sensor excitation and front panel or remote tare. Your meter
may be a basic indicator or it may include analog output or dual relay output. Analog or
dual relay output must be ordered at time of purchase. Analog output is fully scalable
and may be configured as a proportional controller, or to follow your display. Dual 5 amp,
form C relays control critical processes. A mechanical lockout has been included to
guard against unauthorized changes.
2.2 FEATURES
The following is a list of standard features:
* 4-digit, three color Programmable, Big LED display or
4-digit, Standard LED display
* NEMA 4/Type 4 Front Bezel
* ±0.03 % accuracy
* 8 DC input ranges: 0-100 mV, ±50 mV, 0-5 V, 1-5 V,
0-10 V, ±5 V, 0-20 mA, and 4-20 mA
* 5, 10, 12, or 24 Vdc sensor excitation
* Peak detection
* Front panel and remote tare function
* Nonvolatile memory-no battery backup
* 115 or 230 Vac 50/60 Hz power supply or
10-32 Vdc or 26-56 Vdc
The following is a list of optional features:
* Dual 5 amp, form C relay outputs
* Scalable analog output
* Proportional control
* Easy setup for proportional control
