4
Configuring The Meter
34
4.8 SETTING THE SETPOINT 1 DEADBAND S1.DB
Refer to Table 6-1 for a summary list of menu configuration.
Setpoint 1 Deadband S1.DB is not active unless your meter has dual relay output
capabilities. The LED's will display whether the S1.DB is active or not. The Setpoint 1
Default deadband is 0003. To change the deadband (hysteresis) of Setpoint 1, follow
these steps:
1. Press the MENU button until the meter shows S1.DB .
2. Press the ∂TARE button. The meter shows the last previously stored 4-digit
number (0000 through 9999) with flashing 4th digit.
3. Press the ßNT/GRS button to change the value of the flashing digit. If you
continue to press the ßNT/GRS button, the flashing digit's value continues to
change.
4. Press the ∂TARE button to scroll to the next digit.
5. Press the MENU button to store your selection. The meter momentarily shows
STRD , followed by S2.DB (Setpoint 2 Deadband).
To Next Page
