Factory Preset Values
9
SECTION 9. FACTORY PRESET VALUES
Table 9-1. Factory Preset Values
MENU ITEM FACTORY PRESET VALUES
INPT Input Type: 0-100 (0-100 mV) input
DEC.P Decimal Point Position: FFFF
RD.S.O Reading Scale and Offset:
0-100 mV = 0-1000
RD.CF Reading Configuration:
R.1=R (Ratiometric)
R.2=4 (10 µV resolution for unipolar &
25 µV resolution for bipolar)
R.3=F (Filtered value)
R.4=G (Gross/Net reading)
COLR Normal Color Display:
RED or GRN (Note: depending how unit was ordered)
S1.CF Setpoint 1 Configuration:
S.1=A (Setpoint is Active above)
S.2=U (Setpoint is Unlatched)
S.3=N (Net reading)
S2.CF Setpoint 2 Configuration:
S.1=A (Setpoint is Active above)
S.2=U (Setpoint is Unlatched)
S.3=N (Net reading)
S1.DB Setpoint 1 Deadband: 0003
S2.DB Setpoint 2 Deadband: 0003
OT.CF Output Configuration:
O.1=E (Analog output is Enabled)
O.2=C (Analog output is Current)
O.3=N (Analog output follows the Net value)
OT.S.O Output Scale and Offset:
0-1000 = 4-20 mA DC
LK.CF Lock Out Configuration
RS=E (Enable the RESET button in the Run Mode)
SP=E (Enable setpoint changes)
L3=0 (Display setpoint values)
BRIT H.BrT (Brightness Level)
SP1 Setpoint 1 Value: 0000
SP2 Setpoint 2 Value: 0000
Sensor Excitation 10 Vdc
