4
Configuring The Meter
3838
4.10.2 Selecting Analog Output as Current or Voltage
1. Press the MENU button until it shows OT.CF , then press the ∂TARE button twice.
or
Press the ∂TARE button from 0.1.
The meter shows one of the following:
• O.2=C (Analog output = current) (Default)
• O.2=V (Analog output = voltage)
2. Press the ßNT/GRS button to toggle between available choices.
3.
Press the ∂TARE button to select analog output or proportional control or press the
MENU
button to store your selection and enter OT.S.O (Output Scale and Offset).
4.10.3 Selecting Analog Output or Proportional Control
1. Press the MENU button until it shows OT.CF , then press the ∂TARE button twice.
or
Press the ∂TARE button from 0.2.
The meter shows one of the following:
• O.3=N (Net Reading) (Default)
• O.3=G (Gross Reading)
2. Press the ßNT/GRS button to toggle between available choices.
3.
Press the
MENU
button to store your selection.
The meter momentarily shows
STRD , followed by
OT.S.O
(Output Scale and Offset).
