4
Configuring The Meter
32
4.6.3 Assigning Setpoint 1 Values to Net or Gross Readings
1. Press the MENU button until S1.CF displays, then press the ∂TARE button twice.
or
Press the ∂TARE button from S.2.
The meter shows one of the following:
• S.3=N Setpoint 1 assigned to net reading (Default)
• S.3=G Setpoint 1 assigned to gross reading
2. Press the ßNT/GRS button to toggle between available choices.
3. Press the MENU button to store your selection(s). The meter momentarily shows
STRD, followed by S2.CF (Setpoint 2 Configuration).
4.7 USING SETPOINT 2 CONFIGURATION S2.CF
Refer to Table 6-1 for a summary list of menu configuration.
Setpoint 2 Configuration S2.CF is not active unless your meter has dual relay output
capabilities. The LED's will display whether the S2.CF is active or not. You may use
Setpoint 2 Configuration S2.CF for the following:
• To set the setpoint's active band above or below your chosen value
• To select whether the setpoint operation is latched or unlatched
• To assign setpoint values to the net or gross reading
4.7.1 Setting Setpoint 2's Active Band
1. Press the MENU button until the meter shows S2.CF.
or
2. Press the ∂TARE button. The meter shows one of the following:
• S.1=A (Active above the setpoint) (Default)
• S.1=B (Active below the setpoint)
3. Press the ßNT/GRS button to toggle between available choices.
4. Press the ∂TARE button to select if Setpoint 2 is latched/unlatched or press the
MENU button to store your selection. The meter shows S1.DB.
