2
About
The Meter
8
2.5 BACK OF THE METER
Figure 2-3
shows the label describing the connectors on the back of the meter
.
T
able 2-2
on the following page gives a brief description of each connector at the back of the meter
.
Figure 2-3. Connectors (AC-Powered and DC-Powered Detail)
POWER & INPUT
CONNECTIONS(STRAIN)
17
19
