Bode 100 User Manual
10
1.2 Block Diagram
Figure 1-1:
Block diagram
CH 2 receiver
CH 1 receiver
DDS signal sourceMicrocontroller
CH 1
ADC
CH 2
ADC
DC power
converter
DC power
input
USB
interface
CH 1 INPUT
CH 2 INPUT
OUTPUT
