Common Functions
8 Common Functions
In this section you can find the Bode Analyzer Suite basics. The section
provides an overview of the toolbars, menus and commands common to all
measurement modes. Further on, this section explains how to change the
measurement range, how to export the data and how to store and load
configuration files.
8.1 Toolbars, Menus and Commands
Figure 8-1:
Toolbar
Figure 8-2:
Calibration toolbar
Open
New Save
Search and Reconnect Device
Device Configuration
Continuous Measurement
Stop Measurement
Contents
Gain/Phase
Impedance/Reflection
Frequency Sweep
Single Measurement
Print
Print Preview
Frequency Sweep
(External Coupler)
Start User Calibration Start Probe Calibration
Switch Impedance calibration on/off
Switch Gain/Phase calibration on/off
Switch Gain/Phase calibration on/off
Switch Impedance calibration on/off
