Omicron Bode 100 User Manual

101
Advanced Functions
9 Advanced Functions
The Bode 100 provides additional features extending the Bode Analyzer Suite
functionality described in sections 3 to 8 of this User Manual. This section
describes these advanced functions which will make your daily measurement
tasks with the Bode 100 even easier.
9.1 Advanced Display Options
In all measurement modes, the Bode Analyzer Suite provides several
possibilities to visualize the measurement results according to your needs. You
can control these advanced display options through the shortcut menus and/or
buttons in the main window.
9.1.1 Gain/Phase and Impedance/Reflection Mode
The shortcut menu in the Gain/Phase and Impedance/Reflection mode is
shown below. To open the shortcut menu, right-click a diagram in the graphical
display.
Figure 9-1:
Gain/Phase and
Impedance/Reflection
mode shortcut menu
