Bode 100 User Manual
116
9.2 Advanced Sweep Options
In the Frequency Sweep and Frequency Sweep (External Coupler) modes,
you can choose between continuous sweep and single sweep
measurements. In most applications, it is recommended to use the continuous
sweep measurement since all measurement data is periodically updated.
Single Sweep You can use the single sweep measurement to capture one-time events or
to produce a stable curve before using the Copy or Copy with Settings
function.
DUT Delay,
Measurement
Period
In the Configuration window, you can find the DUT delay and
Measurement period boxes.
Figure 9-15:
DUT delay and
Measurement period
fields
The measurement period indicates the time the Bode 100 requires to perform
measurement at one frequency point. By multiplying this value with the selected
number of measurement points you can get an estimate of the expected sweep
time.
