Omicron Bode 100 User Manual

Bode 100 User Manual
136
12.2 Power Requirements
Table 12-2:
Power requirements
12.3 Absolute Maximum Ratings
Table 12-3:
Absolute maximum
ratings
Characteristic Rating
AC power adapter
Input voltage/frequency 100…240 V / 47…63 Hz
DC power supply
Output voltage/output power +10…24 V / 10 W
Inner connector +10…24 V
Outer connector Ground
Inner diameter 2.5 mm
Outer diameter 5.0 mm
Characteristic Absolute Maximum Rating
DC power input
DC supply voltage +28 V
DC supply reverse voltage
(device does not work)
–28 V
CH 1 INPUT, CH 2 INPUT connectors (high impedance)
Maximum AC input signal 50 Vrms for 1 Hz…1 MHz
30 Vrms for 1 MHz…2 MHz
15 Vrms for 2 MHz…5 MHz
10 Vrms for 5 MHz…10 MHz
7 Vrms for 10 MHz…40 MHz
Maximum DC input signal 50 V
CH 1 INPUT, CH 2 INPUT connectors (low impedance)
Maximum input power 1 W (= 7 Vrms)
OUTPUT connector
Maximum reverse power 0.5 W
