Bode 100 User Manual
62
Congratulation! You learned how to use the Frequency Sweep mode.
How to:
• Visualize measurement data in a graph
• Set configuration parameters like the input resistor and bandwidth
• Set sweep parameters like start and stop frequencies
• Use cursors to read single measurement points
• Calibrate and compensate for the cable
Frequency sweepers
have an easier time to
get the picture.
Go back to the Frequency Sweep mode window in 5 "Frequency Sweep Mode"
on page 43 and try things out.
