Bode 100 User Manual
74
Congratulation! You learned how to use the Frequency Sweep (External Coupler)
mode.
How to:
Connect an external coupler
Set configuration parameters like the input resistor and bandwidth
Calibrate and compensate the connection system
Display reflection in VSWR format
Display impedance in polar format
Remove the effect of noise
Sometimes external
couplers help to make a
match and to enhance
the power.
Go back to the Frequency Sweep (External Coupler) window in 6 "Frequency
Sweep (External Coupler) Mode" on page 63 and try things out.
