CP TD1 Reference Manual V 1.44
12
• Do not connect any cable to the test object without a visible grounding of the
test object.
• The high-voltage cable is double-shielded and therefore safe. However, the
last 50cm (20 inch) of this cable have no shield. Therefore, during a test
consider this cable a life wire and due to the high-voltage life-hazardous!
•Never remove any cables from the CP TD1 or the test object during a test.
• Keep clear from zones in which high voltages may occur. Set up a barrier or
establish similar adequate means.
• Both low-voltage measuring cables must always be well attached and tightly
connected to the CP TD1’s measuring inputs IN A and IN B.
Make sure to insert the red and blue marked cables into the corresponding
measuring inputs: IN A = red, IN B = blue.
Tighten the plugs by turning them until you feel a stop.
Note: Tighten the plugs manually. Do not use any tools for that because that
can damage the plugs or connectors.
Do not use any other cables than the ones supplied by OMICRON electronics.
Orderly Measures
The CP TD1 Reference Manual or alternatively the e-book in PDF format has
always to be available on site where the CP TD1 is being used. It must be read
and observed by all users of the CP TD1.
The manufacturer and/or distributor is not liable for damage resulting from
improper usage. The user alone assumes all responsibility and risk.
Following the instructions provided in this User Manual is also considered part
of being in accordance with the regulations.
Warning: When the CPC 100 is switched on, consider this part of the cable
has to be in the high-voltage area due to a hazard of electric shock!
Warning: The CP TD1 may be used only as described in this Reference
Manual. Any other use is not in accordance with the regulations.
