Omicron CP TD1 Reference Manual

CP TD1 Reference Manual V 1.44
126
11.5.2 Optional Accessories
TH 3631 Temperature and Humidity Meter
Use the optional device TH 3631 to measure ambient temperature, the test
object temperature and humidity. Once these values were measured, enter them
into the respective entry fields of the TanDelta test card’s Settings Page at
"Compensations" (refer to 3.4 on page 30).
Characteristic Rating
Temperature
Range –10…+60ºC (+14…+140 F)
Resolution 0.1ºC (0.18 F)
Accuracy ±0.4ºC (±0.72 F)
Humidity
Range 5…95% relative humidity
Resolution 0.1%
Accuracy 2.5%
Battery 9 V block cell or 9 V NiCd Accu
Weight 150 g (0.066 lbs)
Dimensions (w x h x d): 71 ×141× 27 mm (2.8 × 5.6 × 1.1")
