CP TD1 Reference Manual V 1.44
36
4. Once all test cards are prepared and the parameters set, make sure the
safety key lock is in position "release" (horizontal).
5. Start the test by pressing the green I/O (test start/stop) push-button on the
CPC 100 front panel.
6. If a potentially hazardous voltage and/or current level is applied to the
CPC 100 outputs, the red signal red light "I" starts flashing.
4.4 Disconnection
1. Switch off the high voltage with the I/O (test start/stop) push-button.
Note: Even if you switched off the CPC 100, wait until the red I / O warning light
is fully extinguished. As long as this warning light is lit, there is still voltage
potential on the output. The green warning light indicates that the CPC 100
outputs are not activated.
2. Press the Emergency Stop button on the CPC 100 front panel.
Warning: If you have a cardiac pacemaker, do not use the CP TD1! Before
operating the CP TD1, make sure there is no person with a cardiac pacemaker
in the immediate vicinity.
Warning: Never touch any metallic terminals and / housing components
without a visible ground connection!
Note: • A test can only be started in the Test Card View and
with all preconditions met (refer to the CPC 100
Reference Manual).
• If voltages
≥ 1 kV are to be applied, after pressing the
I/O (test start/stop) push-button for the first time a
warning message appears on the screen.
Only after the I/O push-button is pressed a second
time, the voltage is applied to the CPC 100 output.
Rather than starting a test and activating the outputs,
pressing the I/O (test start/stop) push-button will then
pop up a message box notifying you about this
problem.
