CP TD12/15 User Manual
16 OMICRON
2.2.3 CPC 80 front panel
Figure 2-3: CPC 80 front panel
Test card functions
File functions
Settings
Menu keys
Context-dependent
Key lock
Locks front panel
Display
Emergency stop
button
Soft-touch
keyboard
Navigation
elements
Test
Start/Stop
Tab
selector
I/O
status lights
