Omicron CP TD12 User Manual

OMICRON 29
Application
3.4 Disconnecting the CP TD12/15
1. End the test.
2. Verify that the test has ended by checking the status lights of the Control device:
The green status light must be on and at the same time the red status light must be fully off.
3. Lock the Control device to avoid any unauthorized execution of tests.
Note: For more details, refer to the corresponding User Manual of the Control device.
4. Ground and short-circuit the test object’s terminals using a suitable grounding set.
5. Disconnect the booster cable from the Control device.
6. Disconnect the booster cable from the CP TD12/15.
7. Disconnect the serial cable from the CP TD12/15.
8. Disconnect the HV- and LV-cables from the CP TD12/15 and the test object.
9. Disconnect the measurement ground from the test object and the CP TD12/15.
WARNING
Death or severe injury caused by high voltage or current possible
The green status light indicates that the outputs of the Control device are not activated.
► Even if you switched off the Control device, wait until the red status light is off. As long
as this status light is on, there is still voltage potential on the output.
