CP TD12/15 User Manual
62 OMICRON
7.2 Mechanical data
7.3 Environmental Conditions
Table 7-17: Mechanical data
Characteristic Rating
Dimensions
(W × H × D)
CP TD12/15 460 × 317 × 223 mm
18.1 × 12.5 × 8.8 inches
Weight CP TD12
23 kg / 51 lb
CP TD15
24 kg / 53 lb
Table 7-18: Climate
Characteristic Rating
Temperature
Operating –10…+55 °C / +14…+131 °F
Storage and
transportation
–20…+70 °C / –4…+158 °F
Max. altitude 2000 m
Relative humidity 5…95 %; no condensation, tested according to IEC 60068-2-78
Table 7-19: Noise Immunity
Characteristic Rating
Noise Immunity Electrostatic: 15 mA induced noise into any test lead without losing measurement
accuracy at maximum interference to specimen current of 20:1
Electromagnetic: 500 µT, at 60 Hz in any direction
