OMICRON 17
Introduction
2.2.4 CPC 80 side panel
Figure 2-4: Left side view of the CPC 80
DANGER
Death or severe injury caused by high voltage or current
The Ext. Booster connector is always galvanically connected to mains.
This also applies when no external booster is selected, the green status light (0) is on,
the outputs are turned off or the Emergency Stop button is pressed.
► Handle the Ext. Booster connector with extreme caution.
► Do not use any other booster cables than the ones supplied by OMICRON.
► Do not use booster cables that are frayed or damaged in any way.
Grounding terminal
Mains power switch
Automatic circuit breaker
I>16A
Mains power supply
1 phase, 85 V ... 264 V AC
External booster
