CP TD12/15 User Manual
58 OMICRON
7 Technical data
7.1 Technical data of the CP TD12/15 in combination with
the Control device
7.1.1 High-voltage output
Conditions: Signals below 45 Hz with reduced values possible. Capacitive linear loads.
7.1.2 Measurements
Test frequencies
Only CPC 100 and CPC 80: TanDelta test card: Column "Hz" of the results table
Special displays in the frequency column "Hz" and their meanings:
Table 7-1: CP TD12 – High-voltage output
Terminal U THD I
max
S
max
t
max
High-voltage output 0...12 kV AC < 2 %
300mA 3600VA > 2min
100mA 1200VA > 60min
Table 7-2: CP TD15 – High-voltage output
Terminal U THD I
max
S
max
t
max
High-voltage output 0...15 kV AC < 2 %
300 mA
1
4500 VA
1
1. Depending on Control device and power supply
> 2 min
100mA 1500VA > 60min
Table 7-3: Test frequencies
Range Typical accuracy
1
1. "Typical accuracy" means at temperatures of 23 °C ± 5 K, after a warm-up time of more than 25 min, and in a frequency range
of 45 Hz to 65 Hz, 98 % of all units have an accuracy which is better than specified.
15...400 Hz error < 0.005 % of reading
*50 Hz (*60 Hz) Measurement mode suppressing the mains frequency interferences; doubles
the measurement time.
!30 Hz The selected test voltage is not available in Automatic measurement (applies to
frequencies below 45 Hz only).
?xx Hz Results with reduced accuracy, e.g., in case of a low testing voltage, influences
of partial discharge etc.
