CP TD12/15 User Manual
18 OMICRON
2.2.5 Status lights
The status lights indicate the operational status of the CPC 100 and CPC 80 as a current/voltage source.
Figure 2-5: Status lights
1. Output is switched OFF
Green status light (0)
on
Current/voltage source is
inactive/off
2. Output is switched ON
and/or measurement
process is active
Red status light (I) is
flashing
Dangerous operating
condition
If the CPC 100 or CPC 80 is supplied by mains and switched on,
and no or both status lights are on, the unit might be defective.
► Contact OMICRON support (see "Support" on page 64).
Dangerous operating
condition
Output is switched OFF
Dangerous
operating condition!
Output is switched ON
