OMICRON 61
Technical data
Impedance Z
Inductance Lx (equivalent serial circuit)
Quality factor QF
Power P, Q, S (selective)
Table 7-12: Impedance Z
Range Typical accuracy
1
1. "Typical accuracy" means at temperatures of 23 °C ± 5 K, after a warm-up time of more than 25 min, and in a frequency range
of 45 Hz to 65 Hz, 98 % of all units have an accuracy which is better than specified.
Conditions
1k
Ω...1200 MΩ error < 0.5 % of reading Utest = 2 kV...10 kV
Table 7-13: Inductance Lx
Range Typical accuracy
1
1. "Typical accuracy" means at temperatures of 23 °C ± 5 K, after a warm-up time of more than 25 min, and in a frequency range
of 45 Hz to 65 Hz, 98 % of all units have an accuracy which is better than specified.
1 H...1000 kH error < 0.3 % of reading
Table 7-14: Quality factor QF
Range Typical accuracy
1
1. "Typical accuracy" means at temperatures of 23 °C ± 5 K, after a warm-up time of more than 25 min, and in a frequency range
of 45 Hz to 65 Hz, 98 % of all units have an accuracy which is better than specified.
0...1000 error < 0.5 % of reading + 0.2 %
> 1000 error < 5 % of reading
Table 7-15: CP TD12 – Power P, Q, S
Range Typical accuracy
1
1. "Typical accuracy" means at temperatures of 23 °C ± 5 K, after a warm-up time of more than 25 min, and in a frequency range
of 45 Hz to 65 Hz, 98 % of all units have an accuracy which is better than specified.
0...3.6 kW error < 0.5 % of reading + 1 mW
0...3.6 kVAR error < 0.5 % of reading + 1 mVAR
0...3.6 kVA error < 0.5 % of reading + 1 mVA
Table 7-16: CP TD15 – Power P, Q, S
Range Typical accuracy
1
1. "Typical accuracy" means at temperatures of 23 °C ± 5 K, after a warm-up time of more than 25 min, and in a frequency range
of 45 Hz to 65 Hz, 98 % of all units have an accuracy which is better than specified.
0...4.5 kW
2
2. Depending on Control device and power supply
error < 0.5 % of reading + 1 mW
0...4.5 kVAR
2
error < 0.5 % of reading + 1 mVAR
0...4.5 kVA
2
error < 0.5 % of reading + 1 mVA
