CP TD12/15 User Manual
60 OMICRON
Capacitance Cp (equivalent parallel circuit)
Dissipation factor DF (tan δ)
Power factor PF (cos ϕ)
Phase angle ϕ
Table 7-8: Capacitance Cp
Range Typical accuracy
1
1. "Typical accuracy" means at temperatures of 23 °C ± 5 K, after a warm-up time of more than 25 min, and in a frequency range
of 45 Hz to 65 Hz, 98 % of all units have an accuracy which is better than specified.
Conditions
1 pF...3 µF
error < 0.05 % of reading + 0.1 pF Ix < 8 mA, Utest = 2 kV...10 kV
error < 0.2 % of reading Ix > 8 mA, Utest = 2 kV...10 kV
Table 7-9: Dissipation factor DF
Range Typical accuracy
1
1. "Typical accuracy" means at temperatures of 23 °C ± 5 K, after a warm-up time of more than 25 min, and in a frequency range
of 45 Hz to 65 Hz, 98 % of all units have an accuracy which is better than specified.
Conditions
0...10 % (capacitive)
error < 0.1 % of reading + 0.005 %
2
2. Reduced accuracy of DF at mains frequency or its harmonics. Mains frequency suppression available by precisely selecting
a mains frequency of *50Hz or *60Hz in the "Hz" column.
f = 45...70 Hz, I < 8 mA,
Utest = 2 kV...10 kV
0...10000 % error < 0.5 % of reading + 0.02 % Utest = 2 kV...10 kV
Table 7-10: Power factor Pf
Range Typical accuracy
1
1. "Typical accuracy" means at temperatures of 23 °C ± 5 K, after a warm-up time of more than 25 min, and in a frequency range
of 45 Hz to 65 Hz, 98 % of all units have an accuracy which is better than specified.
Conditions
0...10 % (capacitive)
error < 0.1 % of reading + 0.005 %
2
2. Reduced accuracy of PF at mains frequency or its harmonics. Mains frequency suppression available by precisely selecting
a mains frequency of *50Hz or *60Hz in the "Hz" column.
f = 45...70 Hz, I < 8 mA,
Utest = 2 kV...10 kV
0...100 %
error < 0.5 % of reading + 0.02 % Utest = 2 kV...10 kV
Table 7-11: Phase angle
ϕ
Range Typical accuracy
1
1. "Typical accuracy" means at temperatures of 23 °C ± 5 K, after a warm-up time of more than 25 min, and in a frequency range
of 45 Hz to 65 Hz, 98 % of all units have an accuracy which is better than specified.
Conditions
-90 °...+90 ° error < 0.01 ° Utest = 2 kV...10 kV
