SAA2 Warning Lamp
25 OMICRON
Figure 8: SAA2 system in transport case
Figure 9: SAA2 signal lamp
Signal lamp
SAA2 dongles
SAA2 control unit
Power supply
Mounting ring
Magnets or M4 nuts (max. 0.8 Nm torque)
Red LEDs
Green LEDs
In/Out plug from control unit, a connector wire to another signal lamp or SAA2 dongle
NOTE! If not connecting to further SAA2 signal lamps the unused In/Out connector must
be terminated with a SAA2 dongle.
