Adjustment of jogging operation
• This function is for adjusting the speed control during jogging operation. As this speed control pa-
rameter is used only in jogging operation, jogging operation with a speed response faster than
during normal operation can be performed.
• For details on parameters, refer to the parameters (3014Hex-02Hex to 3014Hex-07Hex) for
speed control during normal operation that are applicable in 7-5-1 Speed Control Settings
on
page 7-26. There are no parameters relating to the notch filter for jogging.
2-step acceleration/deceleration
• For details on the 2-step acceleration/deceleration function, refer to 6-6-4 2-step Acceleration/Decel-
eration Function on page 6-37.
Reset
• For details on a reset, refer to 6-8-1 Reset Function on page 6-43.
6 Basic Settings
6-59
M1 Series EtherCAT Type User’s Manual (I670)
6-9 Multi-function Input
6
6-9-1 Multifunction Input Selection
