Omron 3G3M1-A4004-ECT User Manual

Single-phase 200 V, 2.2kW
Three-phase 200 V, 3.7 kW
Three-phase 400V
, 3.0/4.0kW
(4)
(3)
(6)
(5)
Single-phase 200 V, 3.7kW
Three-phase 200 V, 5.5/7.5kW
Three-phase 400V
, 5.5/7.5kW
(4)
(3)
(1)
(2)
(5)
(6)
(1) Cooling Fan Cover (4) Inverter Case
(2) Cooling Fan (5) Surface cover (Terminal block cover)
(3) Cooling Fin (6) Surface cover (Backing plate)
