Item Single-phase 200 V
Rated input voltage
*3
Single-phase 200 to 240 V, 50/60 Hz
Rated input cur-
rent [A]
*4
HHD 1.8 3.3 5.4 9.7 16.4 22 45.4
HND
3.3 4.9 7.3 13.8 20.2 26 -
Rated output voltage Single-phase 200 to 240 V (with AVR)
Rated output cur-
rent [A]
*5
HHD 1 1.6 3 5 8 11 17.5
HND
1.2 1.9
3.5
*7
6.0
*7
9.6
*7
12
*7
-
Braking torque
*6
[%]
HHD 150 100 70 40 40
HND
75 73 68 48 29 -
Braking
resistor
circuit
Regenerative
braking
Built-in braking resistor circuit (discharge resistor separately mounted)
Minimum con-
nection resist-
ance [
Ω]
100 to 120 40 to 120
Short circuit current rating
[kA]
100
W
eight [kg] Approx.
0.5
Approx.
0.5
Approx.
0.7
Approx.
0.9
Approx.
1.5
Approx.
1.7
Approx.
3.8
*1. The maximum applicable motor capacity is given for a standard four-phase motor. When selecting an inver-
ter, select not just by kW but also ensure that the inverter rated output current is greater than the motor rat-
ed current.
*2.
In calculating the rated capacity, the rated output voltage is assumed to be 200 V or 240 V.
*3. A voltage higher than the power supply voltage cannot be output.
*4. When Carrier Frequency (3004Hex-1BHex) is set to the following or below, derating is required.
HHD mode...AB001 to A2037: 8 kHz
HND mode...AB001 to A2022: 4 kHz
For derating, refer to A-1 Derating Table on page A-2.
*5. The following shows the calculated value when the power supply capacity is 500 kVA (10x the inverter ca-
pacity when the inverter capacity exceeds 50 kVA) and when a %X = 5% power supply is connected.
*6. The numeric value is the average braking torque per individual motor. (Varies according to motor efficiency)
*7. Allowable ambient temperature of 40°C or below of AB004, AB007, AB015 and AB022.
The rated output current in the HND mode decreases by 2% for every temperature increase of 1°C when
the ambient temperature is 40°C or more.
*8. The maximum applicable motor capacity is 2.2 kW when the input voltage is 220 to 240 V.
*9. The maximum applicable motor capacity is 3.0 kW when the input voltage is 220 to 240 V.
Common Specifications
Item Specifications
Enclosure rating
*1
Open type (IP20)
1 Overview
1-13
M1 Series EtherCAT Type User’s Manual (I670)
1-3 Specifications
1
1-3-1 Standard Specifications
To Next Page
