Omron 3G3M1-A4004-ECT User Manual

Index
(hex)
Sub-
index
(hex)
Object name
Setting
range
Unit
Default set-
ting
Data
attrib-
ute
Size
Ac-
cess
PDO
map
Complete
access
Modes of
operation
1018 --- Identity Object --- --- --- --- --- --- --- Possible ---
00 Number of en-
tries
--- --- 04 hex --- 1 byte
(U8)
RO --- --- ---
01 Vendor ID --- --- 00000083
hex
--- 4 bytes
(U32)
RO --- --- ---
02 Product Code --- --- Refer to the
table.
--- 4 bytes
(U32)
RO --- --- ---
03 Revision Num-
ber
--- --- Refer to the
table.
--- 4 bytes
(U32)
RO --- --- ---
04 Serial Number --- --- Refer to the
description.
--- 4 bytes
(U32)
RO --- --- ---
• This object gives the device information.
• Subindex 01 hex V
endor ID gives the manufacturer identifier.
• Subindex 02 hex Product Code gives the code specific to each model.
Specifications Model Product Code
3-phase 200 VAC 0.1 kW 3G3M1-A2001-ECT 00000164 hex
0.2 kW 3G3M1-A2002-ECT 00000165 hex
0.4 kW 3G3M1-A2004-ECT 00000166 hex
0.75 kW 3G3M1-A2007-ECT 00000167 hex
1.5 kW 3G3M1-A2015-ECT 00000168 hex
2.2 kW 3G3M1-A2022-ECT 00000169 hex
3.7 kW 3G3M1-A2037-ECT 0000016A hex
5.5 kW 3G3M1-A2055-ECT 0000016B hex
7.5 kW 3G3M1-A2075-ECT 0000016C hex
11 kW 3G3M1-A2110-ECT 0000016D hex
15 kW 3G3M1-A2150-ECT 0000016E hex
1.85 kW 3G3M1-A2185-ECT 0000016F hex
Single-phase 200 VAC 0.1 kW 3G3M1-AB001-ECT 00000151 hex
0.2 kW 3G3M1-AB002-ECT 00000152 hex
0.4 kW 3G3M1-AB004-ECT 00000153 hex
0.75 kW 3G3M1-AB007-ECT 00000154 hex
1.5 kW 3G3M1-AB015-ECT 00000155 hex
2.2 kW 3G3M1-AB022-ECT 00000156 hex
3.7 kW 3G3M1-AB037-ECT 00000157 hex
3-phase 400 VAC 0.4 kW 3G3M1-A4004-ECT 00000158 hex
0.75 kW 3G3M1-A4007-ECT 00000159 hex
1.5 kW 3G3M1-A4015-ECT 0000015A hex
2.2 kW 3G3M1-A4022-ECT 0000015B hex
3 kW 3G3M1-A4030-ECT 0000015C hex
4 kW 3G3M1-A4040-ECT 0000015D hex
5.5 kW 3G3M1-A4055-ECT 0000015E hex
7.5 kW 3G3M1-A4075-ECT 0000015F hex
11 kW 3G3M1-A4110-ECT 00000160 hex
15 kW 3G3M1-A4150-ECT 00000161 hex
18.5 kW 3G3M1-A4185-ECT 00000162 hex
22 kW 3G3M1-A4220-ECT 00000163 hex
• Subindex 03 hex Revision Number gives the device revision number.
Appendices
A-12
M1 Series EtherCAT Type User’s Manual (I670)
