Omron 3G3M1-A4004-ECT User Manual

Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
0C M11 Output Current
Monitor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 399.99
0 --- % Possible
(TxPDO)
0D M12 Output Voltage
Monitor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.0 to 1,000.0
0 --- V Possible
(TxPDO)
0E M13 Operation Com-
mand at Final
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0000 to FFFF hex
Bit 15: RST
Bit 14: DI7
Bit 13: DI6
Bit 12: ---
Bit 11: EN
Bit 10: ---
Bit 9: ---
Bit 8: ---
Bit 7: ---
Bit 6: DI5
Bit 5: DI4
Bit 4: DI3
Bit 3: DI2
Bit 2: DI1
Bit 1: REV
Bit 0: FWD
0
--- --- Possible
(TxPDO)
Appendices
A-49
M1 Series EtherCAT Type User’s Manual (I670)
A-4 Lists of Manufacturer Specific Objects 2
(Inverter Parameters)
A
A-4-1 M Group Parameter List (Monitor 1)
