Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
4F E78 Overtorque/
Undertorque De-
tection Level at
Forward Power
Running
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 300
100
√
% Possible
50 E79 Torque detection
1 Detection T
im-
er
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.01 to 600.00
10
√
s Possible
51 E80 Overtorque/
Undertorque De-
tection Level at
Reverse Regen-
eration
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 300
100
√
% Possible
63 E98 Input Terminal
[DI6] Function
Selection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 188 (normally-open output)
1,000 to 1,188 (normally-close out-
put)
Refer to 8-2-1 Multifunction Input Se-
lection on page 8-23.
98 --- --- Possible
64 E99 Input Terminal
[DI7] Function
Selection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 188 (normally-open output)
1,000 to 1,188 (normally-close out-
put)
Refer to 8-2-1 Multifunction Input Se-
lection on page
8-23.
99 --- --- Possible
301F 03 E102 2nd RUN Com-
mand Selection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
1: Terminal command (FW or RV)
5: EtherCAT
5
--- --- Possible
04 E103 Acceleration
Stop Frequency
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00: Disable
0.00 to 590.00
0.0 --- Hz Possible
05 E104 Acceleration
Stop Time
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.0: Disable
0.1 to 60.0
0.00 --- s Possible
Appendices
A-118
M1 Series EtherCAT Type User’s Manual (I670)
