Omron 3G3M1-A4004-ECT User Manual

Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
06 E105 Deceleration
Stop Frequency
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00: Disable
0.01 to 590.00
0.00 --- Hz Possible
07 E106 Deceleration
Stop Time
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.0: Disable
0.0 to 60.0
0.0 --- s Possible
08 E107 Multi-step Fre-
quency Selection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: Binary (CF1 to CF4)
1: Bit (SF1 to SF7)
0 --- --- Possible
0C E111 Jogging Opera-
tion Selection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: Free run stop on jogging stop
, disabled in operation
1: Deceleration stop on jogging stop
, disabled in operation
2: DC injection braking on jogging
stop
, disabled in operation
3: Free run stop on jogging stop
, enabled in operation
4: Deceleration stop on jogging stop
, enabled in operation
5: DC injection braking on jogging
stop
, enabled in operation
4 --- --- Possible
0D E112 1st Torque Boost
Function Selec-
tion
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: Manual torque boost
1: Automatic torque boost
1 --- --- Possible
0E E113 2nd Torque
Boost Function
Selection
0F E114 DC Injection
Braking Selection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: External DC injection braking
1: External DC injection braking/
setting frequency
2: Setting frequency
0 --- --- Possible
Appendices
A-119
M1 Series EtherCAT Type User’s Manual (I670)
A-4 Lists of Manufacturer Specific Objects 2
(Inverter Parameters)
A
A-4-6 E Group Parameter List (Terminal Functions)
