Omron 3G3M1-A4004-ECT User Manual

Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
06 P05 1st Online Tun-
ing Function Se-
lection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: Disable
1: Enable
0
√
--- Possible
07 P06 1st Motor Arma-
ture Resistance
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 500.0
10.55 --- A Possible
08 P07 1st Motor Param-
eter %R1
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 50.00
3.17
√
% Possible
09 P08 1st Motor Param-
eter %X
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 50.00
11.47
√
% Possible
0A P09 1st Slip Compen-
sation Gain for
Driving
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.0 to 200.0
100.0
√
% Possible
0B P10 1st Slip Compen-
sation Response
Time
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.01 to 10.00
0.12
√
s Possible
0C P11 1st Slip Compen-
sation Gain for
Braking
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.0 to 200.0
100.0
√
% Possible
0D P12 1st Rated Slip
Frequency
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 15.00
1 --- Hz Possible
0E P13 1st Iron Loss
Factor 1
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 20.00
2.86
√
% Possible
11 P16 1st Magnetic Sat-
uration Factor 1
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.0 to 300.0
92
√
% Possible
12 P17 1st Magnetic Sat-
uration Factor 2
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.0 to 300.0
84.2
√
% Possible
13 P18 1st Magnetic Sat-
uration Factor 3
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.0 to 300.0
70.5
√
% Possible
Appendices
A-130
M1 Series EtherCAT Type User’s Manual (I670)
