Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
14 P19 1st Magnetic Sat-
uration Factor 4
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0.0 to 300.0
58.3
√
% Possible
15 P20 1st Magnetic Sat-
uration Factor 5
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0.0 to 300.0
46.1
√
% Possible
1F P30 1st PM Motor
Starting Method
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0: Pull-in by current
1: IPM motor type 1
2: SPM motor type
3: Pull-in by current for IPM motor
4: IPM motor type 2
1 --- --- Possible
29 P40 Reserved Do not use. --- --- --- ---
2A P41 Reserved Do not use. --- --- --- ---
36 P53 1st Motor %X
Correction Factor
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0 to 300
100
√
% Possible
38 P55 1st Motor Torque
Current under
V
ector Control
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0.00 to 500.0
16.71 --- A Possible
39 P56 1st Induced Volt-
age Factor under
Vector Control
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
50 to 100
95 --- % Possible
3A P57 Reserved Do not use. --- --- --- ---
3D P60 1st PM Motor Ar-
mature Resist-
ance
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0.000 to 50.00
0.253 --- Ω Possible
3E P61 1st PM Motor d-
axis Inductance
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0.00 to 500.0
4.77 --- mH Possible
3F P62 1st PM Motor q-
axis Inductance
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0.00 to 500.0
10.70 --- mH Possible
40 P63 1st PM Motor In-
duced Voltage
Ke
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0 to 240 (200 V class series)
0 to 500 (400 V class series)
177 --- V Possible
Appendices
A-131
M1 Series EtherCAT Type User’s Manual (I670)
A-4 Lists of Manufacturer Specific Objects 2
(Inverter Parameters)
A
A-4-8 P Group Parameter List (Motor 1 Parameters)
To Next Page
