Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
41 P64 1st PM Motor
Iron Loss
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0.0 to 20.0
100% = Motor rated current
5.50
√
% Possible
42 P65 1st PM Motor d-
axis Inductance
Magnetic Satura-
tion Correction
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0.0 to 100.0 (100.0% = No magnetic
saturation)
999: Factory default
*1
999
√
% Possible
4B P74 1st PM Motor
Reference Cur-
rent at Starting
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
10 to 200
100% = Motor rated current
80
√
% Possible
54 P83 Reserved Do not use. --- --- --- ---
55 P84 Reserved Do not use. --- --- --- ---
56 P85 1st PM Motor
Flux Limitation
Value
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
50.0 to 150.0
999: Factory default
*1
999
√
% Possible
57 P86 Reserved Do not use. --- --- --- ---
58 P87 1st PM Motor
Reference Cur-
rent for Magnetic
Pole Detection
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0 to 200
100% = Motor rated current
60 --- % Possible
59 P88 Reserved Do not use. --- --- --- ---
5A P89 Reserved Do not use. --- --- --- ---
5B P90 1st PM Motor
Overcurrent Pro-
tection Level
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0.00: Disable
0.01 to 500.0
50.00 --- A Possible
60 P95 1st PM Motor
Magnetic Pole
position Offset
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0.0 to 359.9
999: Offset not adjusted
*1
999
√
°
Possible
*1. For SDO communications and PDO communications, it is 7FFF hex.
