Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
13 A18 2nd Auto-tuning
Selection Func-
tion Selection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: Disable
1: Tune the motor parameters while
stopped
2: T
une the motor parameters while
rotating
5: Tune the motor %R1 and %X
while stopped
0 --- --- Possible
14 A19 2nd Online tun-
ing Function Se-
lection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: Disable
1: Enable
0
√
--- Possible
15 A20 2nd Motor Arma-
ture Resistance
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 500.0
10.55 --- A Possible
16 A21 2nd Motor Motor
Constant %R1
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 50.00
3.17
√
% Possible
17 A22 2nd Motor Motor
Constant %X
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 50.00
11.47
√
% Possible
18 A23 2nd Slip Com-
pensation Gain
for Driving
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.0 to 200.0
100.0
√
% Possible
19 A24 2nd Slip Com-
pensation Re-
sponse Time
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.01 to 10.00
0.12
√
s Possible
1A A25 2nd Slip Com-
pensation Gain
for Braking
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.0 to 200.0
100.0
√
% Possible
1B A26 2nd Rated Slip
Frequency
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 15.00
1 --- Hz Possible
1C A27 2nd Iron Loss
Factor 1
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 20.00
2.86
√
% Possible
Appendices
A-149
M1 Series EtherCAT Type User’s Manual (I670)
A-4 Lists of Manufacturer Specific Objects 2
(Inverter Parameters)
A
A-4-10 A Group Parameter List (Motor 2 Parameters)
