Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
3D J60 PID Control I In-
tegral Time 2
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0.0 to 3,600.0
0
√
s Possible
3E J61 PID Control D
Differential T
ime
2
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0.00 to 600.00
0
√
s Possible
3F J62 PID Control
Block Selection
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0000 to 0003 hex
Bit 1: PID output ratio selection
0: Ratio to frequency reference
1: Ratio to maximum output fre-
quency
Bit 0: PID output polarity selection
0: Plus (Addition)
1: Minus (Subtraction)
0 --- --- Possible
40 J63 Overload Stop
Item Selection
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0: Torque
1: Current
0
√
--- Possible
41 J64 Overload Stop
Detection Level
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
20 to 200
100
√
% Possible
42 J65 Overload Stop
Mode Selection
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0: Disable
1: Deceleration stop
2: Free run stop
3: T
orque limit operation (Decelera-
tion)
0
--- --- Possible
43 J66 Overload Stop
Operation Mode
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0: During constant speed running
and deceleration
1: During constant speed running
2: Anytime
0
√
--- Possible
44 J67 Overload Stop
Detection Timer
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0.00 to 600.00
0
√
s Possible
