Code Description Remarks
21 RS-485 communications
22 Fieldbus (Reserved)
23 Support Tool
Example: RUN Command Source Monitor (3010-1D hex) = 0001 hex
00Hex 0
1Hex
→ 1 = Terminal command (FW or RV)
Data Format [68]: Frequency Reference Source Code
Code Description Remarks
0 Digital Operator (Increment/Decre-
ment key) (No output frequency
takeover)
Same as the selection for Frequency Reference Selection
(3004-02 hex/3006-1F hex)
1 Analog voltage input (terminal
[AI1])
2 Analog current input (terminal [AI2]
(AII))
3 Analog voltage input (terminal
[AI1]) + analog current input (termi-
nal [AI2] (AII))
5 Analog voltage input (terminal AI2
(AIV))
7 UP/DOWN control
8 Digital Operator (Increment/Decre-
ment key) (Output frequency take-
over)
10 Pattern operation
13 Pulse train input or Frequency cal-
culation
21 RS-485 communications
22 Fieldbus (Reserved)
23 Support Tool
24 Multi-step Frequency
25 Jogging Frequency
30 PID Control Operator Process
31 PID Control Analog Process
33 PID Control UP/DOWN control
34 PID Control Communication Proc-
ess
36 PID Control Multi-Step Terminal
Process
255 Not Selected
Example: Frequency and PID Command Source Monitor (3010-1E hex) = 000A hex
00Hex 0
AHex
→ 10 = Pattern operation
Data Format [74]: Integer Data (Positive), in 10 Hours
Example: 1st Remaining Time before the Next Motor Maintenance
(3003-52 hex) = 12,340 h
12340 ÷ 10 = 04D2
h
→
04H D
2H
