Parame-
ter No.
EtherCAT Object Parameter
Communica-
tion data for-
mat
(2 bytes)
M38 3003-27 hex Output Voltage Effective Value Monitor on Alarm 3
M39 3003-28 hex Operation Command Monitor on Alarm 14
M40 3003-29 hex Operation Status 1 Monitor on Alarm 16
M41 3003-2A hex Latest Output Terminal Information Monitor on Alarm 15
M42 3003-2B hex Cumulative Operation Time Monitor on Alarm 1
M43 3003-2C hex Main Circuit DC Voltage Monitor on Alarm 1
M44 3003-2D hex Inverter Internal Air Temperature Monitor on Alarm 2
M45 3003-2E hex Heat Sink Temperature Monitor on Alarm 2
M46 3003-2F hex Life of Main Circuit Capacitor Monitor 3
M47 3003-30 hex Life of PC Board Electrolytic Capacitor 74
M48 3003-31 hex Life of Cooling Fan 74
M49 3003-32 hex Input Terminal [AI1] Input Voltage Monitor 29
M56 3003-39 hex Input Terminal [PTC] Input Voltage Monitor 29
M57 3003-3A hex Electric Angle Monitor 3
M58 3003-3B hex Rotor Angle Monitor 3
M59 3003-3C hex Motor Electronic Thermal Monitor 1
M61 3003-3E hex Inverter Internal Air Temperature Monitor 4
M62 3003-3F hex Fin Temperature Monitor 4
M63 3003-40 hex Load Factor Monitor 6
M64 3003-41 hex Motor Output Monitor 6
M65 3003-42 hex Motor Output Monitor on Alarm 29
M66 3003-43 hex Speed Detection Monitor 29
M67 3003-44 hex Transmission Error Transaction Code for RS485 Port 20
M68 3003-45 hex Reserved 29
M69 3003-46 hex Inverter Rated Current 24
M70 3003-47 hex Running Status 3 Monitor 44
M71 3003-48 hex Input Terminal Monitor 14
M72 3003-49 hex Reserved 29
M73 3003-4A hex PID Output Monitor 29
M74 3003-4B hex Running Status 2 Monitor 76
M76 3003-4D hex Service Life of Main Circuit Capacitor Elapsed Time 74
M77 3003-4E hex Service Life of Main Circuit Capacitor Remaining Time 74
M78 3003-4F hex Rotation Speed Command Monitor 2
M79 3003-50 hex Rotation Speed Monitor 2
M81 3003-52 hex 1st Remaining Time before the Next Motor Maintenance 74
M84 3003-55 hex Torque Command at Final 2
M85 3003-56 hex 1st Remaining Startup Times before the Next Motor Mainte-
nance
1
M86 3003-57 hex Latest Light Alarm Factor 41
M87 3003-58 hex Light Alarm Factor Last 41
M88 3003-59 hex Light Alarm Factor 2nd Last 41
M89 3003-5A hex Light Alarm Factor 3rd Last 41
M95 3003-60 hex Cumulative Running Time at Tripping 1
M96 3003-61 hex Fourth Last Alarm Contents 10
M97 3003-62 hex Fifth Last Alarm Contents 10
Appendices
A-200
M1 Series EtherCAT Type User’s Manual (I670)
