Page #819 background imageLoading...
Page #819 background image
Event name Abnormal Setting Related to the PG Option Card Event code 38A30000 hex
Meaning The pulse generator wiring is broken in the circuit.
Source EtherCAT Master Function Mod-
ule
Source details Slave Detection tim-
ing
Continuously
Error attrib-
utes
Level Minor fault Recovery Error reset Log category System log
Effects User program Continues. Operation Motor stops.
Indicators EtherCAT NET RUN EtherCAT NET ERR EtherCAT LINK/ACT
--- --- ---
System-de-
fined varia-
bles
Variable Data type Name
None None None
Cause and
correction
Assumed cause Correction Prevention
(1) The wiring between the pulse
generator and the pulse input ter-
minal is disconnected.
Check if the pulse generator is
correctly connected and there is
no disconnection.
→ Check if the pulse generator is
correctly connected. Or securely
connect the wiring to the terminal
block.
→ Check if the sheath is not
caught in the connector
.
→ Replace it with wire that is not
broken.
None
(2) Strong ambient noise was re-
ceived.
Check the measures against
noise (grounding condition, sig-
nal line or communications cable/
main circuit wiring installation
method, etc.).
→ Take measures against noise.
→ Install the main circuit wiring
as far as possible from the con-
trol circuit wiring.
Excessive noise may be generat-
ed around the inverter. Consider
taking measures against noise.
Attached in-
formation
None
Precautions/
Remarks
None
Appendices
A-273
M1 Series EtherCAT Type User’s Manual (I670)
A-5 Sysmac Error Status Codes
A
A-5-2 Error Descriptions
