A-4 CP1L Programming Examples
SYSMAC CP1L/CP1E Introduction Manual 153
●CP1W-CIF11/12 Setup
Set the DIP switches as follows.
●V1000 Setup
Set the DIP switches as follows.
• SW2-1: ON (terminating resistance present) Terminating resistance for RS422/
485 communication
Next, set the parameters as follows:
No. Setting ON/OFF Content
1 Presence of terminating resistance ON Terminating
resistance
present
2 2/4-wire selection ON 2-wire type
3 2/4-wire selection ON 2-wire type
4 - OFF Always OFF
5 RS control for RD ON Enabled
6 SD control for RD ON Enabled
CPU unit connector
Operation setup
DIP switches
(Rear panel)
No. Name Value Comments
B1 02 Operation command 2 RS-422/485 communication enabled
B1 01 Frequency command 6 Frequency commands from RS-422/485
communication enabled
C1 01 Acceleration time 1 5.0 Acceleration time (sec)
C1 02 Deceleration time 1 5.0 Deceleration time (sec)
H5 09 RS-422/485 communication
Timeout detection
1 Detection enabled, detect errors, stop
deceleration after deceleration time 1 (Default)
U4 19 RS-422/485 communication
Frequency commands and
monitoring
1 Select unit for communication of frequency
commands data and frequency monitoring data.
Unit: 0.01Hz (Default).
H5 01 RS-422/485 communication
Slave address
1 Slave address (slave node number), unit 1
H5 02 RS-422/485 communication
Baud rate
2 Communication baud rate (communication
speed): 9600bps (Default)
H5 03 RS-422/485 communication
Parity
0Even parity
H5 06 RS-422/485 communication
Transmission wait time
10 Sets the response wait time for request messages
received from the master. 10ms (Default).
H5 07 RS-422/485 communication
RTS control
0 RTS control enabled (Default)
