Omron DST1-ID12SL-1 User Manual

77
Remote I/O Allocations Section 3-2
3-2-4 I/O Assembly Data
Input Data
Applicable Terminal: DST1-MRD08SL-1
Applicable Terminals: DST1-MD16SL-1 and DST1-XD0808SL-1
Applicable Terminal: DST1-ID12SL-1
Applicable Terminal: DST1-ID12SL-1
Applicable Terminal: DST1-ID12SL-1
Instance
(hex)
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
203 0 Reserved Safety
Input 3
Safety
Input 2
Safety
Input 1
Safety
Input 0
Instance
(hex)
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
204 0 Safety
Input 7
Safety
Input 6
Safety
Input 5
Safety
Input 4
Safety
Input 3
Safety
Input 2
Safety
Input 1
Safety
Input 0
Instance
(hex)
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
20C 0 Safety
Input 7
Safety
Input 6
Safety
Input 5
Safety
Input 4
Safety
Input 3
Safety
Input 2
Safety
Input 1
Safety
Input 0
1 Reserved Safety
Input 11
Safety
Input 10
Safety
Input 9
Safety
Input 8
Instance
(hex)
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
224 0 Safety
Input 7
Safety
Input 6
Safety
Input 5
Safety
Input 4
Safety
Input 3
Safety
Input 2
Safety
Input 1
Safety
Input 0
1 Safety
Input 7
Status
Safety
Input 6
Status
Safety
Input 5
Status
Safety
Input 4
Status
Safety
Input 3
Status
Safety
Input 2
Status
Safety
Input 1
Status
Safety
Input 0
Status
Instance
(hex)
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
22C 0 Safety
Input 7
Safety
Input 6
Safety
Input 5
Safety
Input 4
Safety
Input 3
Safety
Input 2
Safety
Input 1
Safety
Input 0
1 Safety
Input 3
Status
Safety
Input 2
Status
Safety
Input 1
Status
Safety
Input 0
Status
Safety
Input 11
Safety
Input 10
Safety
Input 9
Safety
Input 8
2 Safety
Input 11
Status
Safety
Input 10
Status
Safety
Input 9
Status
Safety
Input 8
Status
Safety
Input 7
Status
Safety
Input 6
Status
Safety
Input 5
Status
Safety
Input 4
Status
