Omron DST1-ID12SL-1 User Manual

116
Troubleshooting Section 7-2
7-2-2 Test Output Errors
Explicit Message for Reading the Cause of the Error
Note The instance numbers for test outputs 0 to 3 are 1 to 4 (01 to 04 hex), respec-
tively.
Code Error Probable cause Countermeasure
01 hex Configuration invalid The configuration is invalid. Configure the DST1 correctly.
02 hex Overload detected 1. Ground fault or short-circuit of an out-
put signal line
2. Trouble with the connected device
1. Check the wiring.
2. Replace the connected device.
05 hex Stuck-at-high detected 1. The power source (positive side) is in
contact with the output signal line.
2. Trouble with the internal circuit
1. Check the wiring.
2. Replace the DST1.
06 hex Under current was detected
using muting lamp
1. The output signal line is broken or dis-
connected.
2. Trouble with the connected device
1. Check the wiring.
2. Replace the connected device.
Explicit
message
Read/
write
Function Command Response
Service
code
Class
ID
Instance
ID
Attribute
ID
Data
size
Test Output
Cause of Error
Information
Read
Read Reads the cause
for the normal flag
(1 to 4) specified
by the instance ID
turning OFF.
(See note.)
0E hex 09 hex 01 to 04
hex
76 hex - 0 = No error
Or error code
