Omron DST1-ID12SL-1 User Manual

139
DeviceNet Explicit Messages Appendix 1
A-1-2 Explicit Messages
Reading General Status
Setting and Monitoring the Unit Conduction Time
Explicit
message
Read/
write
Function Command Response
Service
code
Class
ID
Instance
ID
Attribute
ID
Data size
General Sta-
tus Read
Read Reads the speci-
fied slave’s status
flags (8 bits)
0E hex 95 hex 01 hex 65 hex - 1 byte
Explicit
message
Read/
write
Function Command Response
Service
Code
Class
ID
Instance
ID
Attribute
ID
Data size
Unit Mainte-
nance Set
Value
Read Reads the set
value for the Unit
Conduction Time
(unit: 0.1 h).
0E hex 95 hex 01 hex 73 hex - 4 bytes
0000 0000 to
FFFF FFFF hex
(0 to
4,294,967,295)
Write Writes the set
value for the Unit
Conduction Time
(unit: 0.1 h).
10 hex 95 hex 01 hex 73 hex 4 bytes
0000 0000 to
FFFF FFFF hex
(0 to
4,294,967,295)
Unit Mainte-
nance
Present
Value
Read Reads the present
value for the Unit
Conduction Time
(unit: 0.1 h).
0E hex 95 hex 01 hex 71 hex 4 bytes
0000 0000 to
FFFF FFFF hex
(0 to
4,294,967,295)
Unit Mainte-
nance Flag
Read Reads the moni-
tor status of Unit
Conduction Time.
0E hex 95 hex 01 hex 72 hex 1 byte
00 hex: Within
range
01 hex: Over range
(over the monitor
value)
