6 Parameters
6 - 54
E5@C-T Digital Temperature Controllers User’s Manual (H185)
6-9 Initial Setting Level
This level is used to set up the basic Digital Controller specifications. In this level, you can set the Input
Type parameter to set the sensor input to be connected, limit the setting range of set points, set the
alarm modes, and perform other operations.
25.0
100.0
Operation
Level
Initial Setting
Level
Control stops.
Control in progress
Control stopped
Press the O Key for at
least 1 s; display will flash.
Press the O Key
for at least 3 s.
Power ON
Press the
O Key
for at
least 1 s.
Adjustment
Level
Press the O Key
for less than 1 s.
Program
Setting Level
PID Setting
Level
To move from any of the levels within the dotted line to the Initial
Setting Level, press the
O
Key for at least three seconds with any
parameter displayed except for the Auto/Manual Switch parameter.
• The Initial Setting Level is not displayed when the Initial
Setting/Communications Protect parameter is set to 2. It
can be used when the Initial Setting/Communications
Protect parameter is set to 0 or 1.
• If the Input Type parameter is set for an analog input, the
following parameters will be set: Scaling upper limit,
Scaling lower limit, and Decimal point.
