Omron E5*C Series User Manual

6 Parameters
6 - 58
E5@C-T Digital Temperature Controllers User’s Manual (H185)
sl-h
SP Upper Limit
sl-l
SP Lower Limit
• These parameters set the upper and lower limits of the set points. A set point can be set
within the range defined by the upper and lower limit set values in the SP Upper Limit and
SP Lower Limit parameters. If these parameters are reset, any set point that is outside of
the new range will be forcibly changed to either the upper limit or the lower limit.
• When the temperature input type and temperature unit have been changed, the set point
upper limit and set point lower limit are forcibly changed to the upper and lower limits of
the sensor.
• For a temperature input, the decimal point position depends on the currently selected
sensor, and for an analog input it depends on the Decimal Point parameter setting.
z Related Parameters
Input Type (Initial Setting Level): Page 6-56
Temperature Unit (Initial Setting Level): Page 6-57
t-u
Program Time Unit
• This parameter sets the time unit for the program.
• This parameter sets the time unit for the following parameters. Always set this time unit
before setting the following parameters.
• Segment Times
• Time Signal ON Times and Time Signal OFF Times
Function
Setting
Parameter name Setting range Unit Default
Set Point Upper
Limit
Temperature
input
SP lower limit + 1 to Input setting
range upper limit
EU 1300
Analog input SP lower limit + 1 to scaling upper
limit
EU 100
Set Point Lower
Limit
Temperature
input
Input setting range lower limit to
SP upper limit - 1
EU −200
Analog input Scaling lower limit to SP upper
limit - 1
EU 0
See
See
Function
Setting
Setting range Unit Default
h-m: hours and minutes
m-s: minutes and seconds
--- h-m: hours and
minutes
