6 - 59
6 Parameters
E5@C-T Digital Temperature Controllers User’s Manual (H185)
6-9 Initial Setting Level
6
t-pr
Step Time/Rate of Rise
Programming
This parameter specifies the segment setting method when a program is set.
There are two methods: Step Time, in which the arrival time and arrival SP are set, and
Rate of Rise Programming, in which the segment type is set (to ramp, soak, or step) and the
values are set.
The setting method that you select does not affect the program patterns that you can create.
z Related Sections
5-15 Program-related Functions (page 5-53)
pru
Time Unit of Ramp Rate
The Step Time/Rate of Rise Programming
parameter must be set to Rate of Rise
Programming.
This parameter sets the time unit for the denominator of the Segment Slope parameter.
Example: If the Segment Ramp Rate parameter is set to 100 and the Time Unit of Ramp
Rate parameter is set to M (minutes), the program SP will change at a rate of
100 per minute toward the segment SP.
z Related Sections
5-15 Program-related Functions (page 5-53)
z Related Parameters
Step Time/Rate of Rise Programming (Initial Setting Level): Page 6-59
Function
Setting
Setting range Unit Default
time: Step time
pr: Rate of rise programming
--- time: Step time
See
See
Function
Setting
Setting range Unit Default
h: Hours
m: Minutes
--- m: Minutes
See
See
