8.4 Adjustment level (l.adj)
8-21
Setting data
These settings are used to adjust overshoot to disturbances.
• Disturbance gain is used to adjust the amount of overshoot caused
by disturbances.
● Related setting data
"Disturbance overshoot adjustment function" (Expansion control
setting level) (P.8-80)
Disturbance gain
Disturbance time constant
Disturbance rectification band
Disturbance judgment width
dogn
dotc
do-b
dojw
CH
l.adj
Function
Setting
Setting data Setting range Units
Default value
Disturbance gain -1.00 to 1.00 − 0.65
Disturbance time constant 0.01 to 99.99 − 1.00
Disturbance rectification band 0.000 to 9.999 %FS 0.000
Disturbance judgment width -99.99 to 99.99 %FS 0.00
Reference
Reference
