Section 8 Setting data
8-36
Setting data
• These settings are used to set the sensor type.
• If these settings are changed, the SP limit settings are returned to
the initial settings. In this case, reset the "SP upper limit" and "SP
lower limit" settings as necessary.
• Refer to the following table to configure the settings. Initial settings
are shaded.
Set the input type switch of each input to match the "Input type" setting
of the corresponding input.
The initial setting is "2". ("TC.PT")
● Related setting data
"Input
∗ temperature units" (Input initial setting level) (P.8-37)
"SP upper limit", "SP lower limit" (Control initial setting level) (P.8-43)
Input 1 input type
Input 2 input type
Input 3 input type
Input 4 input type
i1-t
i2-t
i3-t
i4-t
l.0
Function
Setting
Setting
value
Input
type
Setting range
Input type
switch
(°C) (°F)
0 Pt100(1) -200.0 to 850.0 -300.0 to 1500.0
TC.PT
1 Pt100(2) -150.00 to 150.00 -199.99 to 300.00
2 K(1) -200.0 to 1300.0 -300.0 to 2300.0
3 K(2) -20.0 to 500.0 0.0 to 900.0
4 J(1) -100.0 to 850.0 -100.0 to 1500.0
5 J(2) -20.0 to 400.0 0.0 to 750.0
6 T -200.0 to 400.0 -300.0 to 700.0
7 E 0.0 to 600.0 0.0 to 1100.0
8 L -100.0 to 850.0 -100.0 to 1500.0
9 U -200.0 to 400.0 -300.0 to 700.0
10 N -200.0 to 1300.0 -300.0 to 2300.0
11 R 0.0 to 1700.0 0.0 to 3000.0
12 S 0.0 to 1700.0 0.0 to 3000.0
13 B 100.0 to 1800.0 300.0 to 3200.0
14 W 0.0 to 2300.0 0.0 to 4100.0
15
4 to 20 mA
Depends on scaling
One of the following ranges appears
depending on the scaling:
-19999 to 99999
-1999.9 to 9999.9
-199.99 to 999.99
-19.999 to 99.999
-1.9999 to 9.9999
ANALOG
16
0 to 20 mA
17 1 to 5V
18 0 to 5V
19 0 to 10V
TC.PT
IN1
TYPE
ANALOG
TC.PT
IN1
TYPE
ANALOG
Reference
Reference
