8.9 Input initial setting level (l.0)
8-37
Setting data
• Select Celsius (°C) or Fahrenheit (°F) for the temperature units.
● Related setting data
"Input
∗ Type" (Input initial setting level) (P.8-36)
• These settings are used when the input type is analog input.
• Scaling is carried out for analog input. The display value for "Scaling
input value 1" is set in "Scaling display value 1", and the display
value for "Scaling input value 2" is set in "Scaling display value 2".
• "Decimal point position" is used to specify the decimal point position
of setting data (SP, etc.) for which the units are "EU".
• Scaling settings for inputs 2 to 4 of multi-point input types are set in
channels 2 to 4. Press the key to change to the desired analog
input channel and then set the scaling.
* The units depend on the input type settings.
● Related setting data
"Input
∗ type" (Input initial setting level) (P.8-36)
Input 1 temperature units
Input 2 temperature units
Input 3 temperature units
Input 4 temperature units
i1du
i2du
i3du
i4du
Input type is temperature input
l.0
Function
Setting
Setting range Units Default value
c: °C
f: °F
−
c:
°C
Reference
Reference
Scaling input value 1
Scaling display value 1
Scaling input value 2
Scaling display value 2
Decimal point position
inp.1
dsp.1
inp.2
dsp.2
dp
Input type is analog input
CH
l.0
Function
CH
Setting
Setting data Setting range Units Default value
Scaling input value 1
Input lower limit to
input upper limit
∗
4
Scaling display value 1
-19999 to
Scaling upper limit − 1
EU 0
Scaling input value 2
Input lower limit to
input upper limit
∗
20
Scaling display value 2
Scaling lower limit + 1 to
99999
EU 100
Decimal point position 0 to 4 − 0
Reference
Reference
